RoboPCA: Pose-Centered Affordance Learning from Human Demonstrations for Robot Manipulation
Zhanqi Xiao, Ruiping Wang, Xilin Chen
AI summary
Problem
Current affordance prediction methods separate contact region localization from pose estimation, causing inconsistencies that lead to robotic task failures, while learning from human demonstrations lacks reliable 3D and pose annotations.
Approach
The authors introduce Human2Afford to automatically extract contact points and poses from unlabeled human videos, and RoboPCA, a diffusion-based model that jointly predicts these pose-centered affordances conditioned on RGB-D scenes, object masks, and language instructions.
Key results
- Automated Human2Afford pipeline for extracting pose-centered affordances from human videos
- Diffusion-based RoboPCA framework for joint contact point and pose prediction
- 18.6% improvement in contact point prediction on AGD20K dataset
- 38.5% and 24.9% manipulation success rate gains in simulation and real-world tests
Why it matters
Enables robots to learn reliable, pose-accurate manipulation skills from abundant human videos without costly 3D annotations, advancing general-purpose robotic manipulation.
Abstract
Understanding spatial affordances—comprising the contact regions of object interaction and the corresponding contact poses—is essential for robots to effectively manipulate objects and accomplish diverse tasks. However, existing spa- tial affordance prediction methods mainly focus on locating the contact regions while delegating the pose to independent pose estimation approaches, which can lead to task failures due to inconsistencies between predicted contact regions and candidate poses. In this work, we propose RoboPCA, a pose- centered affordance prediction framework that jointly predicts task-appropriate contact regions and poses conditioned on instructions. To enable scalable data collection for pose-centered affordance learning, we devise Human2Afford, a data curation pipeline that automatically recovers scene-level 3D information and infers pose-centered affordance annotations from human demonstrations. With Human2Afford, scene depth and the in- teraction object’s mask are extracted to provide 3D context and object localization, while pose-centered affordance annotations are obtained by tracking object points within the contact region and analyzing hand–object interaction patterns to establish a mapping from the 3D hand mesh to the robot end-effector orientation. By integrating geometry–appearance cues through an RGB-D encoder and incorporating mask-enhanced features to emphasize task-relevant object regions into the diffusion- based framework, RoboPCA outperforms baseline methods on image datasets, simulation, and real robots, and exhibits strong generalization across tasks and categories.
