GraspControl: Text-Sketch Instruction As an Interface for Controllable Grasp Synthesis
XiaoPeng Wen, songtao tian, Yi Sun
AI summary
Problem
Existing vision-language models struggle to align abstract text instructions with precise spatial object features, making it difficult for robots to execute specific, task-oriented grasps based on human intent.
Approach
The method uses a diffusion model to convert text prompts and 2D object sketches into 2D grasp sketches, which then guide a coarse-to-fine 3D reconstruction pipeline to output accurate 6-DoF grasp poses.
Key results
- Text-sketch guided diffusion model for 2D grasp sketch generation
- Multi-modal attention loss aligning semantic and structural features
- Coarse-to-fine 3D diffusion framework for object-grasp CAD reconstruction
- Validated high-quality, diverse grasp synthesis in simulation and real-world robots
Why it matters
Provides a controllable, human-intent-driven interface for robotic manipulation, advancing reliable object interaction in complex environments.
Abstract
Large vision-language models have been shown to perform complex tasks. However, aligning language instructions with object visual information to enable general inference for robotic grasping poses a significant challenge. To tackle this issue, we introduce GraspControl, a method that leverages grasp language instructions and sketches of objects to control the generation of grasps. Initially, we construct a dataset that augments language instructions with position and orientation information of grasps, and visual information with sketches of the gripper and target objects. Subsequently, we develop a model capable of generating 2D grasp sketches given grasp language and 2D object sketches as input prompts, thereby bridging the gap between the linguistic and visual representations of the object to be grasped. These generated 2D grasp sketches serve as an innovative input modality for grasp synthesis, directing the creation of 3D object models and corresponding 3D grasp poses through a 3D reconstruction module. Furthermore, we incorporate a multi-modal attention loss to ensure the consistency between high-level semantic grasp features and intricate low- level visual features, with a particular emphasis on the grasping area of the object. We evaluate the capabilities of our grasp approach through extensive experiments in both simulated and real-world robotic scenarios. The experimental results confirm that our method can execute grasps in complex environments.
